Unmatched Expandability
With triple function slots and a variety of terminal boards, you have the flexibility to configure a system that's ideally suited to the content to be displayed.



Deep Black Filter
The front protective glass of the plasma display panel incorporates a Deep Black Filter that reduces the amount of external light reflected.

New Real Black Drive System
By reducing the pre-discharge emission when reproducing black, the New Real Black Drive System provides deeper, richer blacks and a stunning 4000:1 contrast.



Long Service Life
A new drive circuit and inner panel improvements gives Panasonic plasma panels a long service life of 60,000hrs, even with their increased brightness.

Multi-Screen Applications
The built-in image-enlarging function makes it easier to set up a multi-display system, with four (2x2), nine (3x3), or 16 (4x4) units.



Vertical Mounting
All models can be positioned vertically to display portrait images, allowing them to serve as effective storefront signboards, without any additional fans.


  MODEL TH-65PHD8WK TH-50PHD8WK TH-42PHD8WK TH-42PWD8WK
PANEL Panel Size 65" (165cm) 50" (127cm) 42" (106cm) 42" (106cm)
  Display Area (mm) 1434 x 806 1106 x 622 920 x 518 920 x 518
  Max. Resolution WXGA (1366 x 768) WXGA (1366 x 768) XGA (1024 x 768) WVGA (852 x 480)
  Contrast Ratio 3000:1 3000:1 3000:1 4000:1
I/O PORT Rear Terminals S-Video (Mini DIN 4-pin)
Video In/Out (BNC)
Audio In L/R (RCA pin x2)
  Rear Fixed PC (Dsub15)
Audio In (M3 jack)
Serial (Dsub9 control, RS232C)
POWER Consumption 615W 395W 295W 240W
  Voltage AC220-240V, 50/60Hz AC220-240V, 50/60Hz AC220-240V, 50/60Hz AC220-240V, 50/60Hz
COLOUR SYSTEM   NTSC, PAL, PAL60, SECAM, Modified NTSC
PACKAGE Unit WxHxD (mm) 1544 x 925 x 99 1210 x 724 x 95 1020 x 610 x 89 1020 x 610 x 89
  Box WxHxD (mm)
  Weight (Net) 78Kg 43Kg 31.5Kg 29.5Kg
  Weight (Gross)
BROCHURE Download Brochure (1.93MB)

    Compatibilty:
OPTIONS TY-ST65-K
Pedestal Stand
  TY-ST08-K
Pedestal Stand
  TY-WK65PV7
Wall Mount
  TY-WK42PV7
Wall Mount
  TY-42TM6A
Component Video
  TY-FB8HM
HDMI Input
  TY-42TM6D
DVI Input
  TY-SP65P7W-K
Speaker Set
  TY-SP50P8W-K
Speaker Set
  TY-SP42P8W-K
Speaker Set
  A full set of available options are available. Please refer to the brochure.
All information is subject to change without notice
